NEW from Meusburger: guiding system for large dies

07.11.2016

The Meusburger product range now includes a guiding system for large transfer and multi-stage dies. The system consists of the E 5040 Guide pillar and the E 5130 Sliding guide bush.

The Meusburger product range now includes a guiding system for large transfer and multi-stage dies. The system consists of the E 5040 Guide pillar and the E 5130 Sliding guide bush.
Both parts correspond to the standards of the automotive industry. Through the special G6 tolerance of the inner diameter of the bush an optimal play between the pillar and the bush is reached. Graphite inserts result in very good emergency operating features of the sliding guide bush. The guiding system for large dies is available from stock at Meusburger in the diameters of 40 to 100 mm.

Further information: www.meusburger.com
